Microphone Wireling - TinyCircuits
Microphone Wireling compared to a dime
Microphone Wireling back view
Microphone Wireling
Microphone Wireling - TinyCircuits
Microphone Wireling compared to a dime
Microphone Wireling back view
Microphone Wireling

Microphone Wireling

AST1030

3 in stock
$ 3.95 Save $ -3.95
OR
DESCRIPTION

This Wireling uses the SPW2430 MEMS Microphone to detect sound and output an analog signal.

New to Wirelings? Check out the Wireling Overview!

Note* 5-Pin Wireling cables not included and sold separately.

    TECH SPECS

    SPW2430 Specs

    • Consists of an acoustic sensor, a low noise input buffer, and an output amplifier
    • Low Current
    • MaxRF protection
    • Ultra-Stable performance

      TinyDuino Power Requirements

      • Voltage: 3.0V - 5.5V
      • Current: 70-110 µA (Normal Mode). Due to the low current, this board can be run using the TinyDuino coin cell option

      Pins Used

      • A5/SCL - I²C Serial Clock line
      • A4/SDA - I²C Serial Data line

      Dimensions

      • 10mm x 10mm (.394 inches x .394 inches)
      • Max Height (from the lower bottom of Wireling to upper top WirelingConnector): 3.70mm (0.15 inches)
      • Weight: 1 gram (.04 ounces)
      NOTES
      • You can also use this Wireling without the TinyDuino – modifying the connecting cable by removing the opposite connector and stripping/tinning the wires, you can solder the connector cable to any other microcontroller board of your choice!
      DOWNLOADS
      Back to Wireling Inputs + Outputs
